Proxmox Install SSL/TLS Certificates

In the video below, we show you how to install a signed SSL/TLS certificate in Proxmox

We show how to create the private key, certificate server request and signed certificate using OpenSSL

Then cover how you can install the key and certificate through the GUI on a standalone server

Because a cluster replicates information among servers, we show a different method so that you can install private keys and certificates for these as well

Steps Taken Using OpenSSL

Login to the Root CA then change to the ca folder
cd ca

1. Create the private key
   openssl genrsa -out private/pvenode1.key 2048

2. Create a configuration file
   nano csr/pvenode1-csr.conf

   [ req ]
   # ‘man req’
   # Used by the req command
   default_bits = 2048
   distinguished_name = req_distinguished_name
   req_extensions = req_ext
   prompt = no

   [ req_distinguished_name ]
   # Certificate signing request
   countryName = GB
   stateOrProvinceName = England
   organizationName = TempLab
   commonName = pvenode1.templab.lan

   [ req_ext ]
   subjectAltName = @alt_names

   [ alt_names ]
   DNS.1 = pvenode1.templab.lan

3. Generate the certificate signing request (CSR)
   openssl req -new -key private/pvenode1.key -sha256 -out csr/pvenode1.csr -config csr/pvenode1-csr.conf

4. Create signed certificate
   openssl ca -config root-ca.conf -notext -in csr/pvenode1.csr -out certs/pvenode1.crt -extensions req_ext -extfile csr/pvenode1-csr.conf

5. Upload the key and certificate
   In the GUI this is relatively simple if you use SFTP for instance
   For a cluster, we’ll replace the existing files
   Connect to a PVE server and navigate to /etc/pve/nodes
   Replicate the folder structure on the local computer e.g.
    pve-node1
    pve-node2
    pve-node3
   Copy the private keys and certificates to the correct local folder and rename them
    pve-ssl.key
    pve-ssl.pem
   Backup the existing files in the server folders on the server e.g. rename them
   Copy the folders from the local computer to the server to copy the signed certificates and new private keys across
   SSH into the server and restart the service
    systemctl restart pveproxy
   Check the new certificate is accepted, if so restart the service on the other servers and check they are working as well
